Operation Steps of Metal Laser Cutter

With the continuous progress of laser technology, the application of laser equipment in industrial production is becoming more and more extensive, and it can process various metal materials, such as common stainless steel, carbon steel, aluminum alloy and other materials. At the same time of convenience, the efficiency and the quality of the production process are also improved, and it also brings greater economic benefits to the enterprise. The correct use of the metal laser cutter is also very important to prolong the life of the equipment and improve the working efficiency of the machine. Han’s super laser cutting machine Today, the manufacturer will introduce the steps of using the metal fiber laser cutting machine.

33

On the surface, using a fiber laser cutting machine only needs to press the button lightly to process the desired product, but in order to make the machine work efficiently, we must also optimize the operation. Ultimately, the specific operation process is as follows:

1. Feeding

First select the material to be cut, and place the metal material smoothly on the cutting table. Stable placement can avoid the jitter of the machine during the cutting process, which will affect the cutting accuracy, so as to achieve a better cutting effect.

2. Check the operation of the equipment

Adjust the auxiliary gas for cutting: select the auxiliary gas for cutting according to the material of the processed sheet, and adjust the gas pressure of the cutting gas according to the material and thickness of the processed material. In order to ensure that the cutting cannot be performed when the air pressure is lower than a certain value, so as to avoid damage to the focusing lens and damage to the processing parts.

3. Import drawings

Operate the console, input the product cutting pattern, and the cutting material thickness and other parameters, then adjust the cutting head to the appropriate focus position, and then reflect and adjust the nozzle center.

4. Check the cooling system

Start the voltage stabilizer and chiller, set and check whether the water temperature and water pressure are normal, and whether they match the water pressure and water temperature required by the laser.

5. Start cutting with metal laser cutter

Turn on the fiber laser generator first, then start the machine bed to start processing. During the processing, you should observe the cutting situation at any time. If the cutting head may collide, the cutting will be suspended in time, and the cutting will continue after the danger is eliminated.

Although the above five points are very brief, in the actual operation process, it takes a lot of time to practice and become familiar with the details of each operation.

34

After the fiber laser cutting machine is used, it is necessary to shut down the machine to reduce the failure of the fiber laser and increase the service life of the machine. The specific operations are as follows:

1. Turn off the laser.

2. Turn off the chiller.

3. Turn off the gas and discharge the gas in the pipeline.

4. Raise the Z-axis to a safe height, turn off the CNC system, and seal the nozzle with transparent glue to prevent dust from contaminating the lens.

5. Clean the site and record the operation of the fiber laser cutting machine for one day. If there is a fault, it should be recorded in time so that the maintenance personnel can carry out diagnosis and maintenance.

In the process of using the metal laser cutter, if you have any questions, you can consult LXSHOW LASER online at any time, and we have professional technicians to help you answer your questions.
